Android OS or Windows OS Tablets
 Android OS or Windows OS Tablets
 Small size tablet Android or Windows PCBA touch
SIZE: 7" 8" 10.1" 12.1" 13.3" 15.6" 18.5" 21.5" 23.6" 27" 32"
PCBA touch screen
Android OS and Windows OS
Customized design
Customized logo

 Android OS or Windows OS Tablets
 Small size tablet Android or Windows PCBA touch
SIZE: 7" 8" 10.1" 12.1" 13.3" 15.6" 18.5" 21.5" 23.6" 27" 32"
PCBA touch screen
Android OS and Windows OS
Customized design
Customized logo

 Small size tablet Android or Windows PCBA touch
All of our products series, every design can be made with following function (Both indoor and outdoor):
***USB version AD player: update advertisement by USB (Stand-alone Version)
***Network version advertising player: update advertisement through internet, support both Android OS and
UCOS OS, Windows OS (Network Version)
***PC version kiosk (Infrared / capacitive touch screen optional): same function as computer, compatible with
Windows7,windows8,Windows XP, Linux, Ubantu, Apple etc. (Built-in PC Version, touch screen optional)
Can also be customized with equipments such as printer, scanner, camera, keyboard,motion sensor, WIFI adaptor etc.
***Android Infrared / capacitive touch screen kiosk: Android OS with touch screen. Can also be customized with
equipments such as printer, scanner, camera, keyboard, motion sensor, WIFI adaptor etc.
***LCD video wall, narrow bezel with HDMI or 4K display
***All kinds of monitors with or W/O touch, 2K or 4K display, open frame, tablets of all size
***Transparent LCD
***Bar type LCD

PRODUCTS:
From Design:
1, Floor standing model (Can be added wheels or no wheels, can be fasten to floor,
can also design according to your idea)
2, Wall mounted screens
3, Hanging screens
4, Horizontal screens
From Function:
1,Monitor with or W/O Touch
2, Digital signage
3, Android touch / Non Touch
4,Windows touch / Non Touch
5,Selfservice terminal: can add camera, printer, scanner, led light, etc.
From Environment:
Indoor and outdoor
Screen Size: 10.1" to 105"
Display: 1920*1080 or 4k 3840*2160
Android: Anvertising screen: RAM 1G, ROM:8G Android OS 4.4.2
Android Touch for use your own Android Software: RAM 2G/4G,
ROM: 8G/16G/32G for your choice, Android OS: 5.1, 6.0 or above.
PC: CPU: J1900. G1840, I3, I5, I7 optional.
Memory: 2G, 4G, 8G 16G optional.
Hard Disk: 500G HHD, 64G SSD, 120G SSD, 240G SSD optional.
Touch: Infrared Touch or capacitive touch optional.
Device: Can add camera, printer, scanner, card reader, password
keyboard, fingerprinter device,mouse, bill acceptor, card dispensor, etc.

Outdoor Kiosk:
1. Waterproof. 2, Dusty proof. 3, lightning protection.
4. With tempered glass, anti glare, ultraviolet-proof.
5. Built-in cooling fan system. 6, Air conditioner Optional
7. Can be with or W/O touch 8, Temperature:-30°C to 50°C
9. Can build in device into kiosk 10, Customized design available.
11. Support Android, Windows or other OS.
12. High Brightness.


LCD Video wall:
Panel: LG, SAMSUNG, AUO/BOE
SAMSUNG, best quality
LG: great quality
BOE/AUO: general quality

Connection way:
1. Using HDMI splitter, stable quality, HDMI resolution.
2. Using DVI looping connection, HDMI resolution.
3. Using DP looping connection, 4K resolution, need signal INPUT and
media resource to be 4k.
4. Can use HDMI matrix for multi-signal input such as PC, camera,etc.
5. Can use large screen processor for signal input, for example:
16 HDMI in, 16 HDMI out, 8 VGA in and 8 VGA out, etc, can be customized.
Can have float windows, picture in picture.

Cables:
HDMI cable, DP cable-if 4k, RJ45 cable, power cables,etc.
Bracket:
1. Normal bracket, can not pop-in and pop-out
2. Pop-in and pop-out bracket, better for future front maintaince
For signal input:
1. Can use media player boxes for input HDMI or 4K signal. Can buy
media player box in local market or buy from us.
2. Can use PC for signal input.
3. Can use camera for signal input with HDMI/SDI output.
4. Matrix
5. Large screen processor
Outer design:
1. Install onto the wall
2. Make as floor standing
3. Floor standing with cabinet below
4. Can make whole unit with frame and cabinet
5. Can make whole unit with floor standing cabinet, frame, can add big tempered glass,
add IR touch frame, make the whole video wall as big touch screen monitor, can also
build in PC or android hardware, make it as Android or PC touch kiosk.
6. Can add motion sensor into this big kiosk, let it have motion sensor function.
7. Can also make curved bracket, to make it as curved video wall.

Product Specs:
Android version

Panel Details	Panel Brand	Samsung/LG
Android	CPU	Quad-Core / Octa-Core
	RAM	2GB/4GB
	ROM ( internal memory )	8GB/16GB
	OS	Android 5.1 or above
Decoding Formats	Video Format	MPG,MPG-1,MPG-2,MPG-4,AVI,MP4,H.264,MOV,WMV,RM,RMVB,etc.
	FHD 1080P Video	YES
	Picture Format	JPG, BMP,PNG,etc.
	Text	TXT
	Audio Format	MP3,WAV
Interface	HDMI Output	1 ( Quad-Core version )
	SD/ TF card slot	1
	USB	1
	RJ45	1
Network	Wifi	available
	3G/4G	optional
	Ethernet	available
Touch screen	option 1	IR touch ( 10 points )
	option 2	capacitive touch (10 points )
Speakers	Speakers	2 x 5W stereo speakers
remote control software	optional
Features
1.Application fields:public places ,for example,shopping mall, restaurant,airport, square, commercial buidings,etc.
2. Outer shell is made of extra good quality metal material and tempered glass.
3.This machine is of android OS design, which could be connected to internet,and supports remote office cotrol .
4.Remotely report system utilization and memory usage.
5.Content plays automatically upon set up of schedule.
6.Control, monitor and design screen layouts remotely by the remote control office.
7.Color for metal outer frame is available with Black color, Shinning-silver color, Golden Color, cream-white color; Color Is Optional.
8.APPs are available on Google Play and APP Store
9.Easy connection to wifi.

PC version

Panel Details	Panel Brand	Samsung/LG/AUTO/ LCD/LED/Chimee
Mini-PC	CPU	i3, i5, i7
	RAM	4GB/8GB
	ROM	500GB HDD or 64/120/240GB SSD
	OS	Windows OS or Linux OS
Interface	HDMI Output	1
	USB	4
	RJ45	2
Network	Wifi	support
	3G	support
	Ethernet	support
Touch screen	option 1	IR touch ( 10-16 points )
	option 2	capacitive touch (10 points )
Speakers	Speakers	2 x 2W or 2 x 5W stereo speakers
remore control software	optional
Features
1.Application fields:public places ,for example,shopping mall, restaurant,airport, square, commercial buidings,etc.
2. Outer shell is made of extra good quality metal material and tempered glass.
3.This machine is with mini PC built in, customers can install Windows or Linux freely. Or let us install OS before shipment.
4.Easy connection to Internet.

Shenzhen TOPADKIOSK is highly specialized in the field of LCD Digital Signage products, LCD DISPLAY, QLED display, OLED display. We have developed our own LCD products Series, such as face recognition terminal with temperature sensor for access control system, safe temperature kiosk, thermal scanner, digital signage, all In One PC, touch screen, lcd video wall, outdoor IP67 High Brightness LCD Digital Signage and TV, etc, the size is available with 7" Inch to 98 Inch etc. These products have been widely used in the USA, Europe, Southeast Asia, the Middle East, Africa and other countries and regions. These products are suitable for advertising in lots of areas, such as buildings, shops, hotels, supermarkets, railway stations, bus stations, airports, taxis, buses and other outdoor areas. Quality and Service is Our Symbol.The most important factor for us to win our customers‘ hearts and found the long-term business relationships with our customers is quality and service. With these years‘ research, development and manufacture, we have accumulated our special experience and methods to control the quality through the whole process of designing, material purchasing, manufacturing and marketing. Especially for the material quality, we have founded firm relationships with our suppliers and even invested in some supply companies to directly control quality. We offer 7*24 hours service to all our clients. Our sales person and after-selfteam will keep on line to answer and solve all questions for you. Providing services beyond our customers‘ expectations is our purpose. Our excellent pre-sales services and after-sales services have earned us many customers‘ hearts. Customized designs are most welcome! Our advantage is to give solution to our clients according to their needs.
